HGD Frame Scaffold, Masson Frame, Flip Lock Frame

  HGD Frame Scaffold, Masson Frame, Flip Lock Frame   Frame Scaffolding is for small to medium sized projects,  including small or medium sized new build, maintenance, roofing, painting and cladding. They are time efficient, safe and stable.  1,Variety: Walk through type & Ladder type 2,Usage: Our products are used widely in bridge, tunnel, petrifaction,  3,Type: scaffolding frames 4,Thickness of the tube:1.8mm,2.0mm,2.2mm,2.4mm or customize 5,Surface treatment:HDG/Galvanized/Pre-galvanized ,ect. 6,Color:silver or customize 7,Certificate:ISO9001:2000  ISO9001:2008 8,Standard:EN74 BS1139 AS1576 9,Advantage:easy erection, strong loading capacity, safety and stability 10,Main components: frame, catwalk, joint pin, cross brace, base jack, u-head jack and caster. shipbuilding, railway, airport, dock industry and civil building etc   Available size

STD/ Ledger(P.G.)mm	Size (mm)	KG	STD/ Ledger(H.D.G.)mm	Size (mm)	kg
Φ42*2.2/Φ42*2.0	1930*1219	15.05	Φ42*2.2/Φ42*2	1930*1219	15.05
Φ42*2.0/Φ42*2.0	1930*1219	14.33	Φ42*2/Φ42*2	1930*1219	14.33
Φ42*2.1/Φ42*2	1930*1219	14.43	Φ42*2.1/Φ42*2	1930*1219	14.43
Φ42*2.2/Φ42*2	1700*1219	13.51	Φ42*2.2/Φ42*2	1700*1219	13.51
Φ42*2/Φ42*2	1700*1219	12.88	Φ42*2/Φ42*2	1700*1219	12.88
Φ42*2.1/Φ42*2	1700*1219	13.20	Φ42*2.1/Φ42*2	1700*1219	13.20
Φ42*2.2/Φ42*2	1524*1219	12.21	Φ42*2.2/Φ42*2	1524*1219	12.21

      Our Certifications     We also Supply:
Galvanized Base Jack, Ringlock Scaffolding System, Adjustable steel props, Adjustable screw jack, Frame system, Metal plank, Scaffolding coupler& Accessories, Cuplock scaffoldingsystem etc.

Contact us if you need more details on h frame scaffolding. We are ready to answer your questions on packaging, logistics, certification or any other aspects about welded frame scaffold、wedge lock scaffolding. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Frame Scaffolding System
